YSH-
Automatic Trimming Intelligent Crosscutting Machine
-
This?machine?is?suitable?for?cutting?big?rolling?packaging?materials such as paper, paper plastic
composite, color printing,Color printing adhesive、Non-woven fabric. Thin film.etc truncated large drum material. Widely used in paper products processing industry, printing and packaging industry, etc.。
1. With the continuous development of processing industry of paper products and printing industry and competition,crosscutting reel material is paper industry and one of theindispensable equipped with printing and packaging industry.
2. Use the electronic parts,such as Europe and the United States and Japan more flexible application of intelligent control,make the simple mechanical operation,convenient maintenance,more to ensure that the machine under the condition of high speed operation to keep cutting precision and mechanical stability.
3 .By the national paper products processing industry and printing and packaging industry users alike.
| 型號(hào) | Model | YSH-1100B | YSH-1400B | YSH-1600B |
| 最大截切寬度 | Max.width of cutting | 1100mm | 1400mm | 1600mm |
| 最大放卷直徑 | Max diameter of unwinding | ￠1400mm | ￠1400mm | ￠1400mm |
| 原材料范圍 | Range of raw material thickness | 80-600g/m2 | 80-600g/m2 | 80-600g/m2 |
| 堆垛高度 | Height of stacking | Max. 1100mm | Max. 1100mm | Max. 1100mm |
| 裁切長度 | Length of cutting |
300-1520mm |
300-1500mm |
300-1500mm |
| 裁切速度 | Speed | ≤200times/min | ≤200times/min | ≤200times/min |
| 裁切精度 | Precision | ±0.2mm | ±0.2mm | ±0.2mm |
| 電源總功率 | Total Power | 7kw | 9kw | 11kw |
| 機(jī)器重量 | Weight | 3600kg | 4000kg | 6100kg |
| 外形尺寸 | Overall dimension (LxWxH) | 5500×1870×1850(mm) | 5500×2170×1850(mm) | 5500×2470×1850 (mm) |
